Signature Motorised Flat Rooflight
Key Information
Signature Motorised Flat Rooflight
A multi-purpose daylight, ventilation and effortless roof terrace access solution.
Industry leading performance
Min. Kerb Height
Min. Kerb Thickness
U Value as low as
G value as low as
Light transmission up to
Wind Load Resistance max test pressure
Our Electric Flatglass Access Hatches are double glazed as standard.
Powered by two 24v actuators, these units can open up to 90o for excellent ventilation and ease of access to roof terraces. The minimum kerb span for these units is 900mm.
Skyway Flatglass Electric Access rooflights are available in the following sizes:
• Square: from 900mm x 900mm up to 1300mm x 1300mm (as standard)
• Rectangular: up to 1300mm x 2900mm (as standard)
Options
- Control unit with battery back-up available
- Choice of switches, wind, rain and temperature sensors
- Synchronised opening mechanism
- Fireman’s switch
- Larger sizes can be accommodated via special order
- We can supply bespoke glass specifications to meet your project requirements
premium colour collection
The premium colour collection has been specially designed to help put together the perfect colour palette for homes.
Every home is different, and our beautiful range of colours takes inspiration direct from nature to harmonise perfectly with your home and its surroundings, ensuring it stays looking good for years to come.
- RAL Colours: Anthracite Grey (RAL 7016) Matt
- White (RAL 9010) and Black (RAL 9005) Matt are also available as standard options
- Bespoke RAL colour options are also available. Matt finish as standard
Glass Specification
Hermetically sealed Double Glazed – IGU:
Outer: Heat Soak Tested Toughened glass
Cavity: Fully Argon filled as standard with Swisspacer warm edge glazing spacer + silicone bonded for a fully UV resistant edge seal
Inner: Laminated or Heat Soak Tested Toughened Glass + Soft Low-E coating for excellent thermal efficiency. For even better thermal efficiency, bespoke glass with ultra-low U Values is available to special order
Hermetically sealed Double Glazed IGU (CWCT Class 1 Non-fragile):
Outer: 10mm or 12mm Heat Soak Tested Toughened glass
Cavity: Fully Argon filled as standard with Swisspacer warm edge glazing spacer + silicone bonded for a fully UV resistant edge seal
Inner: 9.5, 10.8, 11.5, 13.5mm Laminated glass with PVB/ SGP interlayers and Soft Low-E coating to cavity face + polished edges
Hermetically sealed Double Glazed IGU (CWCT Class 2 Non-fragile):
Outer: Heat Soak Tested Toughened glass
Cavity: Fully Argon filled as standard with Swisspacer warm edge glazing spacer + silicone bonded for a fully UV resistant edge seal
Inner: 9.5, 10.8mm Laminated glass with PVB interlayer and polished edges or 11.5, 13.5mm Laminated glass with SGP interlayer and polished edges with Soft Low-E coating
Sandblasted or painted perimeter glass borders optional. Triple & Quadruple Glazed IGU’s with hermetically sealed glass.
Technical Details
Frame Specification
- The Signature motorised flat roof light frames are manufactured from extruded aluminium section to BS 1474, EN 12020-1:2001
- Polyamide thermal breaks in lid and base frame to BS EN ISO 16396-2:2017 making the frames fully thermally broken and extremely thermally-efficient
- Polyester Powder Coated Aluminium to BS EN 12206-1:2004
Product Testing & Certification
- Non-fragility: CWCT TN92, with Class 1 and Class 2 compliant solutions available
- Non-Fragility Class 1 Certified by BRE
- Non-Fragility Class 2 Certified by Vinci
- AA Fire-rated: AA Designation (National Class) or Broof (T4) European Class and Euro Class A1 non-combustible
- Weather tested by BRE to CWCT Class A4 & Class R7
- Skyway Flatglass Protect+ Rooflights Part Q compliant
- Certisecure STS202 tested
British Standards Compliance
- BS 6375-1: 2015+A1:2016 Weathertightness
- BS EN 1026:2016 Air Permeability
- BS EN 1027: 2016 Watertightness
- BS EN 12211: 2016 Wind Resistance
- BS EN 12206-1:2004: Polyester Powder Coating
- BS EN ISO 16396-2:2017 Thermal Break
- BS 1474, EN 12020-1:2001 Extruded Aluminium Sections
- BS EN 14351-1: 2006 + A2: 2016 Window Performance
- BR443: 2019 Conventions for U Value Calculations
* 15-year warranty – subject to terms and conditions.
